- Craft material: high light transmission and environmental friendly
TPU material, good flexibility of TPU material;
- Exterior design: simple and fashionable, exquisite and unique brings
better lighting performance to indoor/outside applications;
|
PN |
N020042UC1LZ((TPU2010) |
|
Voltage |
DC24V |
|
Power |
18W/Roll |
|
LED Quantity |
42LEDs/Roll |
|
SMD Type |
SMD1313 |
|
Color |
W:3000K/4000K/6500K |
|
CRI |
90 |
|
Lumens |
1592lm/Roll |
| Size | 930x20x10mm |
| IP Rate |
IP67 |
| O.T | -25℃ ~ 60℃ |
Remarks:
1. The above parameters are tested based on 1M standard products;
2. The luminous flux is allowed to have an error range of ±10%;
3. The above parameters are typical values;
4. The brightness with in 15M is consistent even if one end is powered;
5. Subject to change without prior notice
6. Length tolerance applies. Actual product dimensions may vary.
Outline Dimension (unit:mm)
Note: Length tolerance applies. Actual product dimensions may vary
